2 Expansion Options
04.09.2016 Mk8 MM Expansion Features Installation and Set-Up Guide Page 21
Exp
Option
Default Range Description
127 10 Steam Flow Start Pressure Offset
The steam flow start pressure is an offset of the required pressure. Steam
flow metering will begin when the actual pressure is within this offset from
the required pressure, as the system would be generating useful steam.
0 Disabled
1 – 100 0.1 – 10.0 bar or 1 – 100 PSI (see parameter 40)
128 10 Steam Flow Stop Pressure Offset
The steam flow stop pressure is an offset below the required pressure. if the
actual steam pressure below this value, then steam flow metering will stop.
0 Disabled
1 – 100 0.1 – 10.0 bar or 1 – 100 PSI (see parameter 40)
129 0 Heat Flow Data Source
For setting 0, the T1, T2 and T3 temperature sensor are wired to the MM,
and the heat flow function is set via expansion option 120. For setting 1,
the same temperature information is fed back up to the MM via connections
to the IO module connected to the DTI. The ID number of the IO module
must be set in expansion option 129.
0 Sensors connected to MM
1 – 10 Sensors connected to IO Unit 1 – 10
130 - Unused
131 - Unused
132 - Unused
133 - Unused
134 - Unused
135 - Unused
136 - Unused
137 - Unused
138 - Unused
139 - Unused
