AUTOFLAME Mk8 MM - Page 48

234.4mm
(9.23in)
42.5mm
(1.67in)
9.0mm
(0.35in)
24.4mm
(0.96in)
15.2mm
(0.60in)
12.0mm
(0.47in)
3 Water Level Control
Page 38 Mk8 MM Expansion Features Installation and Set-Up Guide 04.09.2016
Dimensions
