AUTOFLAME Mk8 MM Installation And Commissioning Guide

HIGH WATER
REQUIRED LEVEL
1st LOW WATER
2nd LOW WATER
CONCENTRIC REDUCER
CONTINUOUS WELD
DRAIN VALVE
CONTINUOUS WELD
BOILER SHELL
BOILER TUBES
CONTINUOUS WELD
1/2” BSP/NPT PARALLEL THREAD
INSTALLED WITH SUPPLIED
COPPER SEALING WASHER
CAPACITANCE PROBE
CONCENTRIC REDUCER
1m (3’0”) OF 10 mm (0.4”) PMA SUPPLIED
1.5m OF 4 CORE SCREEN PRE-WIRED INTO THE PROBE
CONTINUOUS WELD
DRAIN VALVE
CONTINUOUS WELD
BOILER SHELL
BOILER TUBES
HIGH WATER
REQUIRED LEVEL
1st LOW WATER
2nd LOW WATER
HIGH WATER
REQUIRED LEVEL
1st LOW WATER
2nd LOW WATER
CONCENTRIC REDUCER POT DESIGN NOT
ALLOWING CLEANING PROCESS
CONTINUOUS WELD
CAPACITANCE PROBE
INSTALLED WITH SUPPLIED
COPPER SEALING WASHER
1/2” BSP/NPT PARALLEL THREAD
FLANGED FOR CLEANING ACCESS
1m (3’0”) OF 10mm (0.4”) PMA SUPPLIED
1.5m OF 4 CORE SCREEN PRE-WIRED INTO THE PROBE
SIGHT/ GAUGE GLASS CAN BE MOUNTED BETWEEN THESE POINTS
SIGHT/ GAUGE GLASS CAN BE MOUNTED BETWEEN THESE POINTS
FLANGED POT DESIGN ALLOWING
CLEANING PROCESS
3 Water Level Control
04.09.2016 Mk8 MM Expansion Features Installation and Set-Up Guide Page 41
