AUTOFLAME Mk8 MM Installation And Commissioning Guide

3 Water Level Control
04.09.2016 Mk8 MM Expansion Features Installation and Set-Up Guide Page 69
Fault Message Description Type
112 External Level Sensor Input
Low
3mA or lower received from 4-20mA
external level sensor
Alarm
 Check feedback from external level sensor
 Check wiring on terminals EX- and EX+
113 Probe Reading Mismatch Difference between probes/sensor
readings is below mismatch threshold
Alarm
 Check expansion option 27
 Check capacitance probes and sensor readings
114 Probe Serial Numbers are the
Same
One capacitance probe detected on
both capacitance probe terminals
Alarm
 If using two capacitance probes, then two individual probes must be connected
 Check wiring on terminals 1P+, 1P-, 1T+, 1T-, 2P+, 2P-, 2T+ and 2T-
120 Aux WL Inputs Mismatch High water and 1
st
or 2
nd
low auxiliary
level inputs detected simultaneously
Alarm
 Check wiring on terminals HAI, 1AI and 2AI
121 Water Levels Diverse Probes/ sensor detects 1
st
or 2
nd
low
and high water simultaneously
Alarm
 Check water level readings for probes and sensor if optioned
 Re-commission probes with/without sensor
122 Permanent Alarm Reset Input Input held on alarm reset terminal for
more than 10 seconds
Alarm
 Check input on terminal M/R
123 Second Low Probe
Communications Fault
No comms with second low probe Alarm
 Check wiring and screen on terminals 5T+, 5T-, 4P- and 4P+
 Check second low probe
124 Second Low Probe Hardware
Fault
Internal check failed Alarm
 Contact Autoflame
125 Permanent Test Input Input held on test terminal for more
than 60 seconds
Alarm
 Check input on terminal TST
126 Second Low Probe Detected
But Not Optioned
Second low probe connected but not
optioned
Alarm
 Check expansion option 6
 Check wiring on terminals 5T+, 5T-, 4P- and 4P+
 Probe may require commissioning
127 Aux WL Inputs Detect But Not
Optioned
Mains detected on auxiliary WL inputs
but not optioned
Alarm
 Check expansion option 5
 Check wiring on terminals HAI, 1AI and 2AI
130 Feed Water Servo Position
Error
Servomotor is outside of the
commissioned range
Alarm/Warning –
exp. option 20
 Check wiring on terminals P-, FW and P+
 Check signal cable form the MM to the servomotor is screened at one end
 Check that the servomotor is zeroed correctly
 Alarm if expansion option 20 is set
