Options & Parameters
Flame Safeguard (MM80001/FSG) Manual
Page | 55
Opt. #
Default
Range
Description
129
0
BC: VPS Operation
0
VPS operates before start-up
1
VPS operates after shutdown
2
VPS operates before and after
130
2
BC: Gas Valve Configuration
0
No vent valve
1
Vent normally closed
2
Vent normally open
3
No vent valve. Single valve pilot
4
Vent normally closed. Single valve pilot
5
Vent normally open. Single valve pilot
131
1
BC: Fuel valve output configuration
This sets the way multi-fuels are configured on the MM. Setting 0, allows
the configuration of 4 fuels and switching between them is possible using
changeover relays. Setting 1 allows 2 fuels to be configured with each fuel
having its own set of outputs and switching between fuels is possible without
changeover relays. Setting 2 is similar to setting 1 but with the possibility of
fuel Change on the Fly (COF). See section 4 of this guide for the full details.
Fuel curves must be commissioned for each fuel valve output mode. This
option must be set before commissioning the MM.
0
One set of outputs (changeover relays, 4 fuels)
1
Two sets of outputs (no changeover relays, 2 fuels)
2
Two sets of outputs, change on the fly (COF)*
* requires unlock code
132
20
BC: Gas Valve Proving Time
10 – 300
This is the time period for when both gas valves are closed to detect a
change in air pressure for the ‘VPS air proving’ phase, or change in gas
pressure for ‘VPS gas proving’ phase.
Seconds
133
25
BC: Maximum Pressure Change Allowed During VPS
0 – 13400
If MM detects a pressure change greater than this value, a lockout will
occur. See parameter 41 for gas pressure display units.
0 mbar – 1340 mbar (value 25 = 2.5 mbar)
0” WG – 537.777” WG (value 25 = (1.003 ”WG)
0 PSI – 19.435 PSI (value 25 = 0.036 PSI)
134
3
BC: VPS Valve Opening Time
3 – 20
This is the time period for when the phases when a gas valve is opened –
‘VPS Venting’ for the void to vent to atmosphere and ‘VPS Void to Gas’ for
the void to fill with gas.
Seconds
135
0
BC: Purge Time Units/ NFPA Post-Purge
See option/ parameter 118 for the purge timing. For setting 2,
option/parameter 118 must be set to 15 seconds or higher. During the NFPA
post-purge, all the servomotors will remain in the position they were in
before normal shutdown or lockout. The NFPA post-purge will occur under
any normal shutdown or lockout at any point in firing.
0
Purge time in seconds
1
Purge time in minutes
2
NFPA post-purge in seconds
3
NFPA post-purge in minutes
