Technical Specifications
Power supply 230V - 240Va.c. 50Hz
Standby power 2.6 Watts
Geared Motor power 150 Watts
Motor type 24Vd.c. Permanent Magnet
Maximum door opening: Height:
Width:
Weight:
5500mm
5100mm
270kg
Opener Limits Travel 5.5 turns of Door Drum Wheel
Maximum Rated Load 500N
Nominal Load 150N
Duty Cycle 25 Operations/hr
Receiver type UHF Multi-frequency FM Receiver
Receiver code storage capacity 511 X 4 button Transmitter Codes
Receiver Sensitivity – 103 dB
Transmitter frequency UHF Multi-frequency FM Transmitter
Number of code combinations Over 100 billion random codes
Code generation Non-linear encryption algorithm
Controller fuse 10 A slow blow
Transmitter Battery CR - 2032 (3 Volts)
Real Time Clock Battery CR -1220 (1.5 Volts)
Backup Battery 12 Volts 6 Amp Hr x 2
NOTE:
1. The door must be well balanced. A person should be able to lift the door up manually with very little
effort in case of an emergency.
2. Intermittent operations may occur in areas which experience very strong winds. Strong wind puts extra
pressure on the door and tracks which may in turn trigger the safety obstruction detection system
intermittently.
3. If the Safety Beam are not installed then the controller will automatically goes into “Safety Close“
mode. Limited number of features are available in this mode please refer to Section 13.1.
