The standard operation of the opener can be altered by editing various parameters. This section describes the parameters
and the effect they have. Use the VIEWING AND EDITING PARAMETER PROCEDURE (Appendix B) to make changes.
Menu 2.3 Door Reverse Time After Close Obstruction
Normally after a close obstruction, the door will fully open to its open position. After a close obstruction, the open cycle can be reduced from 5
seconds to its full open position.
Menu 5. Motor Settings
Motor speed - The maximum speed the motors run at is controlled by the OPEN AND CLOSE SPEED VOLTAGE
parameter. The default value is the maximum recommended for normal operation. If however the door moves too
quickly for a particular installation, the voltage can be reduced to make the motors run slower.
NOTE: Altering these parameters will cause the travel limits to be cleared.
Menu 6.2 Safety Open Mode
By enabling this parameter, the user can open the door only by holding the open button on the wall control unit or by holding the open input active.
The door can not be opened by the transmitters.
Menu 6.3 First (SB1) Safety Beam Response Mode
The Safety Beams input can be configured to respond in one of eight modes.
i. Reverses Close Cycles In this mode, the Safety Beam input has no effect when opening but will cause the door
to reverse if activated when closing.
ii. Close Cycles Stop In this mode, the Safety Beam input has no effect when opening but will stop the door when
closing.
iii. Open and Close Cycles Stop In this mode, all cycles are prevented from being completed or initiated when the
Safety Beam input is active.
iv. Open input In this mode, open cycle is initiated when the Safety Beam is activated.
v. Swipe input In this mode, open cycle is initiated when the Safety Beam is activated.
vi. Close input In this mode, close cycle is initiated when the Safety Beam is activated.
vii. Ped input In this mode, ped cycle is initiated when the Safety Beam is activated.
viii. Aux O/P trigger In this mode, aux output is triggered when the Safety Beam is activated.
ix. Disabled In this mode, Safety Beam is disabled.
Menu 6.4 Second Safety Beam (SB2) Response Mode
Same as above menu 6.3
Menu 6.5 Third Safety Beam (SB3) Response Mode
Same as above menu 6.3
Menu 6.6 Safety Beam Obstruction Reverse Time Mode
Normally after a Safety Beam obstruction the door will fully open to its open position. After a Safety Beam Close
obstruction, the doors open cycle can be reduced from 5 sec to its full open position.
Menu 6.7 GPI Input
GPI input can be configured as OSC, PED or DST setup. The GPI input terminal is activated by the N/O switch.
i. When GPI Selected As OSC: If the door is moving, the activation of the GPI input or by a transmitter button with the OSC
function assigned will cause the door to stop. The next trigger will move the door in the opposite direction to the last travelled.
ii. When GPI Input Is Configured As PED: The activation of the GPI input or by a transmitter button with PED function assigned will
open the door partially to allow pedestrian access but prevent vehicle access. The position the door is driven to is automatically
set to halfway during setting of the travel limits, but can be adjusted to suit.
iii. When GPI Input Is Configured As SWP: Activation of GPI input in this mode will open the door.
iv. When GPI Input Is Configured As MANUAL OPERATION: Activation of GPI input in this mode will disable all the transmitters.
v. When GPI Input Is Configured As DST: The GPI input can be used to switch between STD time and DST (daylight savings
time). The time selected is the amount of time added to STD time when DST is selected. The Options are OFF, 30, 60, 90 or 120
minutes. The GPI input needs to be constantly active to show day light saving time.
Menu 6.8 PED Input Function
If GPI or Fire Input is selected as PED then these inputs can be configured to a SWIPE type input for pedestrian access.
This provides full functionality with the Safety Beam Triggered Pedestrian Auto-Close function.
Menu 6.9 Open Input Polarity
The OPN input is normally configured for N/O operation. This parameter allows its operation to be changed to N/C.
Menu 6.10 STP Input Polarity
The STP input is normally configured for N/O operation. This parameter allows its operation to be changed to N/C.
Menu 6.11 FIRE Input Polarity
The FIRE input is normally configured for N/O operation. This parameter allows its operation to be changed to N/C.
