GDO-10V3L2 Toro
™
Owner Installation Instructions
OPERATIONAL BUTTONS:
1. Press PREV/NEXT buttons move to Left/Right.
2. Press OPEN/CLOSE buttons to change setting.
3. Press SET button to save changes.
4. Press STOP to return to MENU without saving changes.
NOTE: The System will automatically return to
the main screen after 30 secs if a menu screen is
displayed and no buttons are pressed.
21. Appendix
A - Console Menu Structure
Parameter Min Max Default Step Unit Menu No. Section
Menu 1 - Code Transmitter
STORING TRANSMITTERS 0.0 511 1 13.1
Menu 2 - Current Trips
CLOSE MARGIN 0.0 4.0 0.7 0.1 AMPS 2.1 12.3
OPEN MARGIN 0.0 4.0 0.9 0.1 AMPS 2.2 12.4
REVERSE TIME AFTER CLOSE OBSTRUCTION 5.0 60 FULL 1.0 SEC 2.3 12.5
Menu 3 - Auto Close
STD AUTO-CLOSE TIME
Sets and enables the standard Auto-Close time
0.0 300.0 0.0 1.0 Sec 3.1 16.2
S.B AUTO-CLOSE TRIG Selects the Safety Beam or
combination of Safety Beams to enable the S.B triggered
Auto-Close mode.
None None 3.2 16.3
S.B AUTO-CLOSE TIME Sets and enables the S.B
triggered Auto-Close time
0.0 60.0 0.0 1.0 Sec 3.3 16.3
PEDESTRIAN AUTO-CLOSE TIME Sets and enables the
Pedestrian Auto-Close time
0.0 60.0 0.0 1.0 Sec 3.4 16.4
S.B PEDESTRIAN AUTO-CLOSE TRIG Selects the Safety
Beam or combination of Safety Beams to enable the S.B
triggered Pedestrian Auto-Close mode.
None None 3.5 16.4
S.B PEDESTRIAN AUTO-CLOSE TIME Sets and enables
the PE Pedestrian Auto-Close time
0.0 60.0 0.0 1.0 Sec 3.6 16.4
AUTO-CLOSE AFTER CLOSE OBSTRUCTION
Enables Auto-Close feature after close obstructions
(requires Safety Beams)
Off On Off 3.7 16.5
AUTO-CLOSE AFTER OPEN OBSTRUCTION
Enables Auto-Close feature after open obstructions
Off On Off 3.8 16.5
AUTO-CLOSE AFTER POWER UP
Enables Auto-Close feature power up
Off On Off 3.9 16.5
Menu 4 - Light / Lock Times
ON AFTER CYCLE LIGHT TIME
Time light remains on for after a cycle
0 255 60 1 Sec 4.1 18.1
ON BEFORE OPEN CYCLE LIGHT TIME
Minimum time light is activated for prior to opening
0 25.5 0 0.1 Sec 4.2 18.1
ON BEFORE CLOSE CYCLE LIGHT TIME
Minimum time light is activated for prior to closing
0
25.5 0 0.1 Sec 4.3 18.1
OPEN LOCK TIME Set the time the lock is activated for on
open cycles
0.0 Hold 0.0 0.1 Sec 4.4 18.2
CLOSE LOCK TIME Set the time the lock is activated for
on close cycles
0.0 Hold 0.0 0.1 Sec 4.5 18.2
PRE-OPEN LOCK TIME
Time the lock is activated for prior to opening
0.0 25.5 0.0 0.1 Sec 4.6 18.2
PRE-CLOSE LOCK TIME
Time the lock is activated for prior to closing
0.0 25.5 0.0 0.1 Sec 4.7 18.2
Menu 5 - Motor Settings
OPEN SPEED VOLTAGE
Sets the full speed motor voltage
~12.0 ~24 ~22 ~1 Volts 5.1 Appendix C
CLOSE SPEED VOLTAGE
Sets the full speed motor voltage
~12.0 ~24 ~20 ~1 Volts 5.2 Appendix C
