Owner Installation Instructions GDO-10V3L2 Toro
™
23
Parameter Min Max Default Step Unit Menu No. Section
Menu 6 - Operating Modes
Safety Close Mode Off On On 6.1 16.1
Safety Open Mode Off On Off 6.2 Appendix C
Safety Beam Input Response Mode Sets the S.B response
mode. Options are OPEN and CLOSE cycles stop, Close
cycles stop or Close cycle reverse
OPN & CLS stop
CLS to stop
CLS to reverse
CLS to
reverse
6.3-5 Appendix C
SB REVERSE TIME 5 FULL FULL 1 Sec 6.6 Appendix C
GPI INPUT MODE configure the GPI input. Options are
OSC, PED, SWP and DAY LIGHT SAVING
OSC,
PED, DST
OSC 6.7 Appendix C
PED INPUT = SWIPE MODE Selects PED input functions
as pedestrian access swipe input
Off On Off 6.8 Appendix C
OPN INPUT N/C OPERATION
Selects operating polarity of OPN input
Off On N/O 6.9 Appendix C
STP INPUT N/C OPERATION
Selects operating polarity of STP input
Off On N/O 6.10 Appendix C
FIRE INPUT N/C OPERATION
Selects operating polarity of FIRE input
Off On N/O 6.11 Appendix C
FIRE INPUT MODE configure the fire input. Options are
OPN, CLS and PED
OPN,
CLS, PED
OPN 6.12 Appendix C
REMOTE CODE ENABLED
Selects remote transmitter coding function
Off On On 6.13 Appendix C
ACTIVITY REPORTS Select report to be output Off 255 Off 1 6.14 Appendix C
ACTIVITY REPORT ID
Selects ID for controller, sent with activity report
0 65535 0 1 6.15 Appendix C
VACATION MODE
Selects Vacation Mode - disables remote control
Off On Off 6.16 Appendix C
BATTERY/SOLAR MODE
Selects Battery Backup/Solar operation
Off On On 6.17 Appendix C
PASSWORD
Selects password protection for all changes
Off On Off 6.18 Appendix C
Transmitter Grouping Off On Off 6.19 Appendix C
Fault Auto Reset
Selects Fault Auto Reset
Off On
Off 6.20 Appendix C
LED Low Power Mode
Selects saving the power by turning LEDs Off
Off On Off 6.21 Appendix C
Console OSC Buttons
Selects to lock out the console buttons
Off On On 6.22 Appendix C
AUX OUT O/P can be activated by either LIGHT DRIVE
,CLOCK/TXER / SB, OPEN or CLOSE status
LIGHT
DRIVE
6.23 Appendix C
SBFEC MODE In the event of Safety Beam failure the door
can be closed by pressing and holding a button on remote
or on console
Off On On 6.24 Appendix C
Menu 7 - Time Clock
SET TIME / DATE Off On Off 7.1 17.1
VIEW / EDIT PROGRAMS Off On Off 7.2 17.2
SETTINGS Off On Off 7.3 17.3
Menu 8 - Diagnostics
TEST INPUTS - Controls input display status Inactive 8.1 Appendix D
TEST TRANSMITTERS (TX’ERS) 8.2 Appendix D
DISPLAY HISTORY 8.3 Appendix D
MEMORY USAGE 8.4 Appendix D
SERVICE COUNTER 60,000 8.5 Appendix D
