parameTer deTails – “deviCe” menu of parameTers (ConTinued)
deviCe “neTWorks” parameTers
P26.0 – Address Type:
Description:
Read/Write
Sets the Modbus station number.
Range: Modbus Decimal Value: Default:
1 – 32 linear scale ( 1 = 1 ) 1
Modbus Address: Modbus Format:
16000 ( 3E80 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → Device → Networks → Modbus Network Settings → Address
P26.1 – Baud Rate Hold. Reg. Type:
Description:
Read/Write
Sets the serial communications baud rate.
Range: Modbus Decimal Value: Default (decimal):
• 9600
• 19200
• 38400
• 57600
• 115200
• 0
• 1
• 2
• 3
• 4
• 19200 (1)
Modbus Address: Modbus Format:
16064 ( 3EC0 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → Device → Networks → Modbus Network Settings → Baud Rate
P26.2 – Parity Hold. Reg. Type:
Description:
Read/Write
Sets the serial communications parity bit. Also sets the stop bits.
• No parity uses 2 stop bits.
• Odd/even parity uses 1 stop bit.
Range: Modbus Decimal Value: Default (decimal):
• None
• Even
• Odd
• 0
• 1
• 2
• Even (1)
Modbus Address: Modbus Format:
16128 ( 3F00 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → Device → Networks → Modbus Network Settings → Parity
P26.3 – Traffic LEDs Hold. Reg. Type:
Description:
Read/Write
Allows the user to check the state of the modbus communication network.
• Red LED = Receive. • Green LED = Transmit.
Range: Modbus Decimal Value: Default (decimal):
• Off : The Red and Green LEDs display the SR55 status
information. Turning traffic LEDs on will not allow normal
operating LED states to indicate.
Ex: Flashing red LED for a fault present.
• On : The Red and Green LEDS display the traffic on the Modbus
communications network.
• 0
• 1
• Off (0)
Modbus Address: Modbus Format:
14080 ( 3700 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → Device → Networks → Modbus Network Settings → Traffic LEDs
