Automation Direct Stellar SR55 Series User Manual

Chapter 3: Configuration and Parameters
Page 3–65Stellar
®
SR55 Series Soft Starter User Manual – 1st Ed, Rev F – 09/18/2019
parameTer deTails – “log” menu of parameTers (ConTinued)
Each SR55 is tested at the factory, and each unit may have a brief log history from this
testing.
P17.8 – Last Trip -8 Type:
Description: Read Only
Displays the last Fault trip -8.
• Refer to “Trip Code Descriptions” in this chapter.
Range: Modbus Decimal Value: Default:
• Trip: 0 – 65,535
• Trip Time: hh:mm:ss
• linear scale ( 1 = 1 )
• Time (ms) since midnight
(bytes5,4,3,2) and Days since
01/01/1984 (bytes1,0)
• 0
• GMT
Modbus Address: Modbus Format:
• 60616 ( ECC8 hex )
• 60696 ( ED18 hex )
• 16-bit unsigned
• 6 Bytes
Touchscreen Menu Path:
Home → Log → Trip Log → Last Trip -8
P17.9 – Last Trip -9 Type:
Description: Read Only
Displays the last Fault trip -9.
• Refer to “Trip Code Descriptions” in this chapter.
Range: Modbus Decimal Value: Default:
• Trip: 0 – 65,535
• Trip Time: hh:mm:ss
• linear scale ( 1 = 1 )
• Time (ms) since midnight
(bytes5,4,3,2) and Days since
01/01/1984 (bytes1,0)
• 0
• GMT
Modbus Address: Modbus Format:
• 60617 ( ECC9 hex )
• 60699 ( ED1B hex )
• 16-bit unsigned
• 6 Bytes
Touchscreen Menu Path:
Home → Log → Trip Log → Last Trip -9
log “sTarT CurrenT log” parameTers
P18.0 – Last Peak Current Type:
Description: Read Only
Displays the peak current of the last successful start.
Range: Modbus Decimal Value: Default:
0A – 10,000A linear scale (1 = 1mA)
Current (A) = (Value / 1000)
0A
Modbus Address: Modbus Format:
38400/38401 ( 9600/9601 hex ) 32-bit unsigned
Touchscreen Menu Path:
Home → Log → Start Current Log → Last Peak Current
(Home → Monitor → Last Peak Current)
