Automation Direct Stellar SR55 Series User Manual

Page 3–66 Stellar
®
SR55 Series Soft Starter User Manual – 1st Ed, Rev F – 09/18/2019
Chapter 3: Configuration and Parameters
parameTer deTails – “log” menu of parameTers (ConTinued)
Each SR55 is tested at the factory, and each unit may have a brief log history from this
testing.
P18.1 – Last Peak Start Current -1 Type:
Description: Read Only
Displays the peak current of the last successful start -1.
Range: Modbus Decimal Value: Default:
0A – 10,000A linear scale (1 = 1mA)
Current (A) = (Value / 1000)
0A
Modbus Address: Modbus Format:
38402/38403 ( 9602/9603 hex ) 32-bit unsigned
Touchscreen Menu Path:
Home → Log → Start Current Log → Last Peak Start Current -1
P18.2 – Last Peak Start Current -2 Type:
Description: Read Only
Displays the peak current of the last successful start -2.
Range: Modbus Decimal Value: Default:
0A – 10,000A linear scale (1 = 1mA)
Current (A) = (Value / 1000)
0A
Modbus Address: Modbus Format:
38404/38405 ( 9604/9605 hex ) 32-bit unsigned
Touchscreen Menu Path:
Home → Log → Start Current Log → Last Peak Start Current -2
P18.3 – Last Peak Start Current -3 Type:
Description: Read Only
Displays the peak current of the last successful start -3.
Range: Modbus Decimal Value: Default:
0A – 10,000A linear scale (1 = 1mA)
Current (A) = (Value / 1000)
0A
Modbus Address: Modbus Format:
38406/38407 ( 9606/9607 hex ) 32-bit unsigned
Touchscreen Menu Path:
Home → Log → Start Current Log → Last Peak Start Current -3
P18.4 – Last Peak Start Current -4 Type:
Description: Read Only
Displays the peak current of the last successful start -4.
Range: Modbus Decimal Value: Default:
0A – 10,000A linear scale (1 = 1mA)
Current (A) = (Value / 1000)
0A
Modbus Address: Modbus Format:
38408/38409 ( 9608/9609 hex ) 32-bit unsigned
Touchscreen Menu Path:
Home → Log → Start Current Log → Last Peak Start Current -4
