Automation Direct Stellar SR55 Series User Manual

Chapter 3: Configuration and Parameters
Page 3–67Stellar
®
SR55 Series Soft Starter User Manual – 1st Ed, Rev F – 09/18/2019
parameTer deTails – “log” menu of parameTers (ConTinued)
Each SR55 is tested at the factory, and each unit may have a brief log history from this
testing.
P18.5 – Last Peak Start Current -5 Type:
Description: Read Only
Displays the peak current of the last successful start -5.
Range: Modbus Decimal Value: Default:
0A – 10,000A linear scale (1 = 1mA)
Current (A) = (Value / 1000)
0A
Modbus Address: Modbus Format:
38410/38411 ( 960A/960B hex ) 32-bit unsigned
Touchscreen Menu Path:
Home → Log → Start Current Log → Last Peak Start Current -5
P18.6 – Last Peak Start Current -6 Type:
Description: Read Only
Displays the peak current of the last successful start -6.
Range: Modbus Decimal Value: Default:
0A – 10,000A linear scale (1 = 1mA)
Current (A) = (Value / 1000)
0A
Modbus Address: Modbus Format:
38412/38413 ( 960C/960D hex ) 32-bit unsigned
Touchscreen Menu Path:
Home → Log → Start Current Log → Last Peak Start Current -6
P18.7 – Last Peak Start Current -7 Type:
Description: Read Only
Displays the peak current of the last successful start -7.
Range: Modbus Decimal Value: Default:
0A – 10,000A linear scale (1 = 1mA)
Current (A) = (Value / 1000)
0A
Modbus Address: Modbus Format:
38414/38415 ( 960E/960F hex ) 32-bit unsigned
Touchscreen Menu Path:
Home → Log → Start Current Log → Last Peak Start Current -7
P18.8 – Last Peak Start Current -8 Type:
Description: Read Only
Displays the peak current of the last successful start -8.
Range: Modbus Decimal Value: Default:
0A – 10,000A linear scale (1 = 1mA)
Current (A) = (Value / 1000)
0A
Modbus Address: Modbus Format:
38416/38417 ( 9610/9611 hex ) 32-bit unsigned
Touchscreen Menu Path:
Home → Log → Start Current Log → Last Peak Start Current -8
