Page 3–68 Stellar
®
SR55 Series Soft Starter User Manual – 1st Ed, Rev F – 09/18/2019
Chapter 3: Configuration and Parameters
parameTer deTails – “log” menu of parameTers (ConTinued)
Each SR55 is tested at the factory, and each unit may have a brief log history from this
testing.
P18.9 – Last Peak Start Current -9 Type:
Description:
Read Only
Displays the peak current of the last successful start -9.
Range: Modbus Decimal Value: Default:
0A – 10,000A linear scale (1 = 1mA)
Current (A) = (Value / 1000)
0A
Modbus Address: Modbus Format:
38418/38419 ( 9612/9613 hex ) 32-bit unsigned
Touchscreen Menu Path:
Home → Log → Start Current Log → Last Peak Start Current -9
log “sTop CurrenT log” & evenT Times parameTers
P19.0 – Last Peak Stop Current Type:
Description:
Read Only
Displays the peak current of the last successful stop.
Range: Modbus Decimal Value: Default:
• Peak Current: 0A – 10,000A
• Peak Current Time: hh:mm:ss
• linear scale (1 = 1mA)
Current (A) = (Value / 1000)
• Time (ms) since midnight
(bytes5,4,3,2) and Days since
01/01/1984 (bytes1,0)
• 0A
• GMT
Modbus Address: Modbus Format:
• Peak Current: 39040/39041 ( 9880/9881 hex )
• Peak Current Time: 39104/39105/39106 ( 98C0/98C1/98C2 hex )
• 32-bit unsigned
• 6 Bytes
Touchscreen Menu Path:
Home → Log → Stop Current Log → Last Peak Stop Current
P19.1 – Last Peak Stop Current -1 Type:
Description:
Read Only
Displays the peak current of the last successful stop -1.
Range: Modbus Decimal Value: Default:
• Peak Current: 0A – 10,000A
• Peak Current Time: hh:mm:ss
• linear scale (1 = 1mA)
Current (A) = (Value / 1000)
• Time (ms) since midnight
(bytes5,4,3,2) and Days since
01/01/1984 (bytes1,0)
• 0A
• GMT
Modbus Address: Modbus Format:
• Peak Current: 39042/39043 ( 9882/9883 hex )
• Peak Current Time: 39107/39108/39109 ( 98C3/98C4/98C5 hex )
• 32-bit unsigned
• 6 Bytes
Touchscreen Menu Path:
Home → Log → Stop Current Log → Last Peak Stop Current -1
