MDF/IDF DESIGN: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES
7-19
● Divide the terminations of the distribution cables among the zones in 100-pair increments.
(described earlier in this chapter under Recommended Frames for Terminal Blocks) may be used for a
zoned MDF that is terminating up to 10 modules.
Table 7-6, Module Allocation per Zone with Type-1
Frame, shows the number of modules allocated per zone when you design an MDF with a type-1 frame.
Each type-1 frame can accommodate 3000 jumper pairs per side. Figure 7-10, Zone Arrangement of
Type-1 Frame —
Plan View, and figure 7-11, Zone Arrangement of Type-1 Frame — Front View, Zone
2. show a type-1 frame used in a zone arrangement.
NOTE: Type-1 frames are not recommended for greater than 10 modules.
TABLE 7-6. Module Allocation per Zone with Type-1 Frame
Number of Number of
Number of
Modules
Zones Modules for Zone
1-5
1
1-5
6
2
3,3
7
2
4,3
8
2
4,4
9 2 5,4
10
2
5,5
NOTE: Custom-engineer all installations over 10 modules.
