Avaya 6424D+M - Figure 2-4. Seven Type-2 Frames with 16,800-Pair Capacity

MDF/lDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES
2-7
LEGEND:
G
— GREEN, NETWORK FIELD
Y — YELLOW, AUXILIARY AND MISCELLANEOUS FIELD
W
— WHITE, DISTRIBUTION FIELD
P — PURPLE EQUIPMENT FIELD
S — SPARE WITH CROSS-CONNECT BLOCKS
Figure 2-4. Seven Type-2 Frames with 16,800-Pair Capacity
