Avaya 6424D+M - Figure 10-1. 7-Module System Wall-Mounted on Type-1 Frames; Figure 10-2. 7-Module System Wall-Mounted on Type-2 Frames

10-4
lNSTALLATlON EXAMPLE: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES
Figure 10-1. 7-Module System Wall-Mounted on Type-1 Frames
Figure 10-2, 7-Module System Wall-Mounted on Type-2 Frames, shows a possible arrangement
for a type-2 wall-mounted configuration requiring 12 frames. This arrangement has greater
jumper capacity and room to add another cabinet. It can be used as long as there is no need to
expand the white field. (In figure 10-2, a single cabinet represents white-field cabinets 4 through
8.)
I
I
Figure 10-2. 7-Module System Wall-Mounted on Type-2 Frames
