Avaya 6424D+M - TABLE 2-3. Type-1 Frame Ordering Information

2-8 MDF/lDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES
Ordering
The service center ships all frames with terminal blocks as one comcode. Frames ordered for 110A
hardware come with 110AB1-300 terminal blocks, clear designation strips, and wireways installed.
However, you must specify the 110C-4 connecting block, which is recommended for a System 85 or
DEFINITY Generic 2 traditional system installation.
You also must order insert labels and ladder racks
separately.
Order type-1 frames and connectors according to table 2-3, Type-1 Frame Ordering lnformation;
ordering information for the type-2 frame is in table 7-4, Type-2 Frame Ordering Information.
TABLE 2-3. Type-1 Frame Ordering Information
Comcode
Top
Bottom
Remarks
105 367 692
1200-pair
1800-pair field
Single sided.
connectorized terminated.
with 110C-4
Specify the
blocks
block type.
105 367 718
2400-pair
3600-pair field
Double sided.
connectorized
tcrminated.
with 110C-4
Specify the
blocks
block type.
105 174 148
600-pair
Kit for the
connectorization
—
above frames.
Order one for
single-sided and
two for
double-sided.
105 689 475 3000-pair field
110C
terminated
—
connector must
be ordered
separately.
105 728 414
6000-pair field
110C
terminated
—
connector must
be ordered
separately.
