Avaya 6424D+M - TABLE 4-3. Voice Terminal Loop Ranges

4-4
PORT PACKS/DCP REPEATERS: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES
TABLE 4-3. Voice Terminal Loop Ranges
Voice Terminal Distance (Ft)
Comments
24AWG
26AWG
Analog
All sets
5380 3500
Using SN229 circuit pack
2500 series 18,460
12,000 Using SN228 or SN228B circuit pack
7100 series
13850
9000
Using SN228 or SN228B circuit pack
Hybrid
7203H
3540 2300
7205H 3540 2300
1690 1100
With 1 module
1150
750 With 2 modules
7303S 1540 1000
1000 650
With 1 adjunct
3075
2000
With adjunct power supplied from
the closet or at the workstation
7305S 1000
650
690 450 With 1 adjunct
3075
2000
With adjunct power supplied from
the closet or at the workstation
Digital
740X 5230
3400
With adjunct power supplied from
the closet or at the workstation.
Loop range can be extended 5000
ft with each DCP repeater. A
maximum of 6 DCP repeaters can
be linked together.
7695
5000
Loop range can be extended 5000
ft with each DCP repeater. A
maximum of 6 DCP repeaters can
be linked together.
