2-20 MDF/lDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES
Use the type-2 frame (described under Recommended Frames for Terminal Blocks earlier in this chapter)
to design a zoned MDF that is terminating up to 16 modules. Table 2-6, Module Allocation per Zone
with Type-2 Frame, shows the number of modules allocated per zone when you design an MDF with a
type-2 frame. Each type-2 frame can accommodate 4000 jumper pairs per side. Figure 2-11. Zone
Arrangement of Type-2 Frame —
Plan View,
and figure 2-12, Zone Arrangement of Type-2 Frame —
Front View, Zone 2, show a type-2 frame used in a zone arrangement.
TABLE 2-6. Module Allocation per Zone with Type-2 Frame
Number of
Number of Number of
Modules
zones
Modules for Zone
1-8 1
1-8
9
2
4,5
10
2 5,5
11
2 5,6
12
2 6,6
13
2
6,7
14 2 7,7
15
2 7,8
16
2
8,8
NOTE: Custom-engineer all installations over 16 modules.
