14. INSERT LABELS
This chapter shows partial reproductions of the upper third of each insert label sheet. Table 14-1,
Numerical List of Insert Labels,
lists the labels in numerical order. The representations are grouped by
the following color coding that indicates the source of the terminating leads as follows:
●
Green: network services central office (CO) trunks
●
Purple: equipment ports
●
Yellow: auxiliary cabinet and miscellaneous field
●
Blue: information outlets (IOs)
●
Gray: connections between intermediate distribution fields (IDFs)
●
White: connections between main distribution field (MDF) and the IDFs
