MDF/IDF DESIGN: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES
Ordering
The service center ships all frames with terminal blocks as one comcode. Frames ordered for 110A
hardware come with 110AB1-300 terminal blocks, clear designation strips, and wireways installed. You
must order insert labels and ladder racks separately.
Order type-1 and type-2 frames and connectors according to table 7-3,
Type-1 Frame Ordering
Information,
and table 7-4,
Type-2 Frame Odering Information.
TABLE 7-3. Type- 1 Frame Ordering Information
Comcode Top
Bottom
Remarks
105 639 561
1200-pair
1800-pair field Single sided.
connectorized
field
with male
terminated.
tops
105 639 538 2400-pair
3600-pair field Double sided.
connectorized
field
with male terminated.
tops
105 174 148 600-pair
Kit for the
connectorization
—
above frames.
Order one for
single-sided and
two for
double-sided.
105 689 475
3000-pair field
110C
terminated
—
connector must
be ordered
separately.
105 728 414 6000-pair field
110C
terminated
—
connector must
be ordered
separately.
