7-2 MDF/lDF DESIGN: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES
TABLE 7-1. 300-Pair Terminal Blocks
Product Code Comcode Height (in.)
ll0AB1-300FT*
104049051 10.79
110AB1-300CTM**
104409024 20.37
110AB1-300CBM†
104408091
20.37
NOTE: The meanings for the alphabetic suffixes to the model
codes are as follows:
* Field terminated
** Connectorized w/male connector
† Connectorized bottom w/male
Table 7-2, 100-Pair Terminal Blocks, gives the ordering information for the 100-pair terminal blocks:
TABLE 7-2. 100-Pair Terminal Blocks
Product Code Comcode
Height (in.)
ll0AB1-100FT*
103823845 3.59
ll0AB1-100CT** 104408992 13.29
ll0AB1-100CTM† 104409008
13.29
ll0ABl-100CB‡ 104408026
13.29
ll0AB1-100CBM§ 104408075
13.29
NOTE: The meanings for the alphabetic suffixes to the model
codes are as follows:
* Field terminated
** Connectorized w/female connector
† Connectorized w/male
‡ Connectorized bottom w/female connector
§ Connectorized bottom w/male
When you are enlarging an existing IDF or MDF constructed of terminal blocks other than those in table
7-1,
300-Pair Terminal Blocks, and table 7-2, 1OO-Pair Terminal Blocks, maintain uniformity in the field
by using the same blocks for the expansion that were used for the initial installation. For new
installations, use the previously described terminal blocks.
NOTE: 110A cross-connect blocks cannot accommodate patchcords.
