MDF/lDF DESIGN: SYSTEM 85 AND DEFINITY GENERIC 2 WITH TRADITIONAL MODULES
● Divide the terminations of the distribution cables among the zones in 100-pair increments.
The type-1 frame (described under Recommended Frames for Terminal Blocks earlier in this chapter)
may be used for a zoned MDF that is terminating up to 10 modules. Table 2-5,
Module Allocation per
Zone with Type-1 Frame,
shows the number of modules allocated per zone when you design an MDF
with a type-1 frame. Each type-1 frame can accommodate 3000 jumper pairs per side. Figure 2-9. Zone
Arrangement of Type-1 Frame — Plan View, and figure 2-10, Zone Arrangement of Type-1 Frame —
Front View, Zone 2, show a type-1 frame used in a zone arrangement
TABLE 2-5. Module Allocation per Zone with Type-1 Frame
Number of
Number of
Number of
Modules
Zones Modules for Zone
1-5
1
1-5
6
2 3,3
7
2
3,4
8
2
4,4
9
2
4,5
10
2
5,5
NOTE: Custom-engineer all installations over 10 modules.
