CONTENTS v
7. MDF/IDF DESIGN: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES
7-1
RECOMMENDED TERMINAL BLOCKS
7-1
RECOMMENDED FRAMES FOR TERMINAL BLOCKS 7-5
DESIGNING THE MDF
7-9
DESIGNING THE MDF FOR A RAISED FLOOR 7-24
RECOMMENDATIONS FOR IDF DESIGNS
7-31
INSERT LABELS
7-32
8. ELECTRICAL PROTECTION: DEFINITY GENERIC 2
WITH UNIVERSAL MODULES
RECOMMENDED PROTECTORS
PROTECTION MATRIX
9. PORT PACKS: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES
PORT CIRCUIT PACKS
DCP REPEATERS
10. INSTALLATION EXAMPLE: DEFINITY GENERIC 2
WITH UNIVERSAL MODULES
SIZING THE MDF
CONSTRCUTING THE MDF
11. BRI: DEFINITY GENERIC 2 WITH UNIVERSAL MODULES
BRI TERMINALS
BRI POWER SUPPLIES
12. ADJUNCT POWER SUPPLIES
INDIVIDUAL POWER SUPPLIES
BULK POWER SUPPLY
8-1
8-1
8-2
9-1
9-1
9-4
10-1
10-1
10-3
11-1
11-1
11-2
12-1
12-1
12-2
