22
2EQUIPMENT DESCRIPTION
2.2 OVERVIEW OF THE ALS 450
ALS
450
2.2.3 Technical data
Characteristic values
Labels
Ambient conditions
Dimensions
Casing
Electrical system
1) Customer options
Control system
Emissions
Labelling speed: 0.5 m/min to 55 m/min
Labelling performance: Refer to the service guide
Stop accuracy (at the
dispensing edge): ± 0.5 mm
Unwind unit: Unwinding spindle with
spreader mechanism
Rewind unit: Spreader mechanism
Operation: Programmable, can be set
via the operator panel,
11 data bases available
Speed control: Automatic dispensing
speed, with RPM-
transmitter
Label width
(incl. backing material): 10 mm to 230 mm
Label length
at maximum dispen-
sing speed:
maximum 350 mm
16 mm to 250 mm
Label roll
Outer diameter:
Core diameter:
maximum 400 mm
76.2 mm
Temperature
Operation:
Storage:
5 °C to 40 °C
5 °C to 70 °C
Relative humidity: 30 % to 80 %,
not condensing
Dimensions
Width:
Height:
Depth:
735 mm
795 mm
560 mm
Weight 85 kg
Covering for the control-
electronics:
Polyurethane (PUR),
10 mm thick
Front plate: Aluminium, anodized,
15 mm thick
Power consumption: 500 VA
Mains connection
Nominal voltage: 110 V/120 V/130 V/200 V/
220 V/230 V/240 V
1)
Frequency: 50 Hz / 60 Hz
1)
Type of protection
IP41: protected against vertically
falling drops of water, not
protected against sprayed
water
IP54 (optional): Protected against splash-
ing water and dust layers
Drive system
IP41: 2 stepping motors,
1 AC motor
IP54 (optional): 3 stepping motors
Control electronics:
IP41: Integrated
IP54 (optional): The electronic control unit
and operator panel are built
into a separate switch cab-
inet
Options: – Serial interface
– Roll diameter control
Sound pressure level at
a distance of 1 m: 75 db (A)
