4OPERATION
4.1 ACTIVATION AND SHUT-DOWN
ALS
350
450
Start dispensing labels
– The conveyor belt starts up. The first product reach-
es the product sensor (photoelectric sensor) [43].
– The product sensor sends a start signal.
– The start signal from the product sensor triggers the
dispensing of a label (label feed) using the set val-
ues for dispensing speed, label distance, etc.
– The dispensing of labels automatically runs in the
same manner for the following products.
[43] The product sensor (A) has detected a product (B) at the dis-
pensing edge and sends a start signal.
B
A
