38
3PRIOR TO OPERATING
3.2 INSERT THE LABELLING MATERIAL – ALS 450
ALS
450
3.2.3 Threading the label ribbon
Overview of the threading path diagram
[26] Threading path diagram for label ribbon with the labels on the outside
A Right-hand version B Left-hand version
[27] Threading path diagram for label ribbon with the labels on the inside
A Right-hand version B Left-hand version
A B
A B
