Model E1070 Indicator User Instructions 25
The Model E1070 is a full function, high connectivity indicator for most
weighing applications and process control situations. It is ideal for connected
system weighing applications. The display includes a multi-segment fan
graph for fast visual awareness for checkweighing. Also, the indicator can
perform counting functions, peak weight functions, and act as a remote
display. The indicator also has 11 memory channels for storing data.
Communication ports allow connection to a many peripheral devices and to
DeviceNet, ProfiBus and EtherNet/IP interfaces.
All this in a NEMA 6/4X rated enclosure.
2.1 About This Manual
Major sections of this manual are headed by titles in a black bar like
Introduction above. Subheadings appear in the left column. Instructions and
text appear on the right side of the page. Occasionally notes, tips, and
special instructions appear in the left column.
2.2 Setup and Power-up
Plug the Model E1070 into properly
grounded socket-outlet of the
correct voltage, installed near the
equipment and easily accessible.
Never use the unit without an
appropriate earthground
connection.
Any computer based system
should have a separate, grounded
power circuit. We recommend one
for the Model E1070.
Your indicator will be installed by a qualified Avery Weigh-Tronix distributor.
They will make the required connections to your scale and peripheral
devices.
1. With the unit plugged in, see note at left, press and release the on/off
switch, shown below, to turn the indicator on.
2. The indicator powers up in normal operation mode.
Introduction
2
