Model E1070 Indicator User Instructions 29
OP 3 Lights when output three is activated
PT Lights when preset tare is active
Network &
SensorComm
Status
This is configurable to light to show status of the Network 1,
Network 2 or SensorComm. See note at left.
Accumulator, Count Lights when an accumulation occurs and while in the count and
peak applications
Custom Unit Lights when a custom unit of measure is active
KG Lights when kilograms is the active unit of measure
LB Lights when pounds is the active unit of measure
Checkweigher Lights when checkweighing application is active
Bottom LED color
SCOM:
Red – a cell has been ghosted. Check
the ghost log.
Green – a sensorcomm error has
occurred. Check the error log.
Off – Scale is functioning normally.
Network 1 or 2:
Red – A network error has occurred.
Check the network settings on the
indicator and PLC, and reboot the
indicator.
Green – The network connection has
been established.
Amber – The network is ready for a
connection, but no connection has been
established
