Model E1070 Indicator User Instructions 33
4.2 Supervisor Menu
5. Toggle between the choices using the TARE or UNITS key and press
the ENTER key when your choice is displayed…
M XX is displayed. M stands for minute and XX represents the
current value.
6. Key in the minute and press the ENTER key …
HOUR is displayed.
SETUP (Setup menu) 1. Press the UNITS key…
SETUP is displayed. Use this submenu to print and/or clear
application reports, choose operation modes or values for
applications which have choices and view various function logs.
Each is explained in the following steps.
APP
(Application submenu)
2. Press the PRINT key…
APP is displayed. As stated in the Service menu section of the
manual, applications are enabled in the Service menu but you do
each application’s setup in this area of the Supervisor menu.
PLU
(Product Look Up)
3. Press the PRINT key…
PLU is displayed. This stands for Product Look Up. There are 11
PLU memory channels, numbered 0-10. Each channel contains all
the parameter values and accumulator totals associated with all the
different applications. This menu item lets you print out all the
information in each channel, in all the applications, and/or clear the
information.
The PLU report contains the
following information for each of
the 11 channels:
Channel #
ID #
Gross Accum.
Net Accum.
Count Accum.
Total
Tare Value
Lower Limit
Upper Limit
Piece Weight
Output Wt1
Output Wt2
Output Wt3
4. Press the PRINT key…
PRINT is displayed. Use this item to print out a complete report of
all application parameters and totals.
5. Press the PRINT key …
PORT 1 or PORT 2 is displayed. Use this item to select which port
to use for printing the report. See note at left.
6. Toggle between PORT 1 and PORT 2 using the TARE or UNITS key.
Press the ENTER key when your choice is displayed…
The report is printed and display shows BUSY briefly then returns
to PRINT.
7. Press the UNITS key…
TARE is displayed. Use this item to enable multichannel preset
tares.
8. Press the PRINT key…
ON or OFF is displayed.
9. Toggle between the choices using the TARE or UNITS key and press
ENTER to accept the displayed choice…
The scale must be in the center-of-
zero window for the tare weight to
be accepted.
If ON is chosen, the tare value for each channel can be entered. 0
will be displayed. Use the TARE or UNITS key to change the
channel number. Press the ENTER key when the correct channel
number is displayed to enter the tare value for that channel.
To Next Page
