61
Model E1070 Indicator Service Manual
(NETS) DEVICENET™
1. If D-NET (DeviceNet™) was selected in step 5 above. . .
NODE will appear on the display.
2. Press the PRINT key.
The node address that is currently set is displayed.
3. Key in the desired node address for the DeviceNet™ connection, or
press ENTER to accept the node address that is currently configured.
NODE will reappear on the display.
4. Press the UNITS key
BAUD is displayed.
5. Press the PRINT key to configure the baud rate. . .
The current baud rate is displayed. This may be “125”(125k),
“250”(250k), or “500”(500k).
6. Scroll through the choices by pressing the TARE or UNITS key. Press
the PRINT key when the value you want is displayed. . .
BAUD is displayed.
7. Press the UNITS key. . .
OUT is displayed.
8. Press the PRINT key. . .
DATA 1 is displayed.
9. Press the PRINT key. . .
The display will show something change to “000 FF”, or something
similar. The 000 is the type of output and the FF is the output
token. A list of output tokens and types is shown in Table 4.
10. Use the TARE or UNITS key to change the output type. Use the
SELECT or PRINT key to change the output token. When the desired
type and token appear on the display, press the ENTER key.
DATA 1 is displayed.
11. You can configure up to 16 items of information to output from the
indicator. Press the UNITS key. . .
Display changes to DATA 2.
12. Repeat steps 9 and 10 above to configure up to 16 data items.
13. Press the SELECT key. . .
OUT is displayed.
14. Press the UNITS key. . .
IN is displayed.
15. Press the PRINT key.
DATA 1 is displayed.
Service Menu—OPTION submenu (continued)
