Model E1070 Indicator Service Manual
3. Use the numeric enter method to enter the desired number for the first
octet of the IP address. (###. xxx. xxx. xxx). . .
The second octet of the IP address is shown.
4. Repeat step 4 for all 4 octet numbers of the IP address. (###. ###. ###.
###). After all four parts of the IP address have been entered. . .
IP is displayed.
5. Press the UNITS key. . .
SUBNET is displayed.
6. Press the PRINT key to enter the Subnet mask. This will be a numeric
entry in four parts just like the ip address. (###. ###. ###. ###). After all
four parts of the subnet mask have been entered. . .
SUBNET is displayed.
7. Press the UNITS key. . .
GATE is displayed.
8. Press the PRINT key to enter the gateway address. This will be a
numeric entry in four parts just like the ip address. (###. ###. ###. ###)
After all four parts of the gateway have been entered. . .
GATE is displayed.
9. Press the UNITS key. . .
OUT is displayed.
10. Press the PRINT key. . .
DATA 1 is displayed.
11. Press the PRINT key. . .
The display will show something change to 000 FF, or something
similar. The 000 is the type of output and the FF is the output
token. A list of output tokens and types is shown in Table 4.
12. Press the TARE or UNITS key to scroll through the output types. Press
the SELECT or PRINT key to change the output token. When the
desired type and token appear on the display, press the ENTER key. . .
DATA 1 is displayed.
13. You can configure up to 16 items of information to output from the
indicator. Press the UNITS key to make the display change to DATA 2.
Repeat steps 11 through 13 above to configure up to 16 data items.
14. Press the SELECT key. . .
OUT is displayed.
15. Press the UNITS key. . .
IN is displayed.
16. Press the PRINT key. . .
DATA 1 is displayed.
Service Menu—OPTION submenu (continued)
