Model E1070 Indicator Service Manual
(NETS) Remote I/O
Service Menu—OPTION submenu (continued)
1. If rio (Remote I/O) was selected in step 5 above. . .
Baud appears on the display.
2. Press the PRINT key.
The current baud rate is displayed. This may be “57.6” (57.6k),
“115.2” (115.2k), or “230.4” (230.4k).
3. Scroll through the choices by pressing the TARE or UNITS key. Press
the PRINT key when the value you want is displayed.
BAUD is displayed.
4. Press the UNITS key
RADDR is displayed.
5. Press the PRINT key to configure the rack address. . .
The current rack address is displayed.
6. Key in the desired rack address. This value may be between 0 and 59.
Press the F1 key when the correct rack address has been entered.
RADDR is displayed.
7. Press the UNITS key
RSIZE is displayed.
8. Press the PRINT key to configure the rack size.
The current rack size is displayed. This may be “1/4”,”1/2”, “3/4”,
or “full”.
9. Scroll through the choices by pressing the TARE or UNITS key. Press
the PRINT key when the value you want is displayed.
RSIZE is displayed.
10. Press the UNITS key
RQUATR is displayed.
11. Press the PRINT key to configure the starting quarter.
The current setting for starting quarter is displayed. This may be
“1st”,”2nd”, “3rd”, or “4th”.
12. Scroll through the choices by pressing the TARE or UNITS key. Press
the PRINT key when the value you want is displayed.
RQUATR is displayed.
13. Press the UNITS key
LRACK is displayed.
14. Press the PRINT key to configure the last rack setting.
The current setting for last rack is displayed. This will be “yes” or
“no”.
