Model E1070 Indicator Service Manual
Service Menu—OPTION submenu (continued)
15. Toggle between “yes” and “no” with the TARE or UNITS key. Press the
PRINT key when the value you want is displayed.
LRACK is displayed.
16. Press the UNITS key
IOTYPE is displayed.
17. Press the PRINT key to configure the IO Type.
The current setting for IO Type is displayed. This will be cyclic or
block.
18. Toggle between the choices with the TARE or UNITS key. Press the
PRINT key when the value you want is displayed.
IOTYPE is displayed.
19. Press the UNITS key. . .
OUT is displayed.
20. Press the PRINT key. . .
DATA 1 is displayed.
21. Press the PRINT key.
The display will show something change to “000 FF”, or something
similar. The 000 is the type of output and the FF is the output
token. A list of output tokens and types is shown in Table 4.
22. Use the TARE or UNITS key to change the output type. Use the SE-
LECT or PRINT key to change the output token. When the desired type
and token appear on the display, press the F1 key.
DATA 1 is displayed.
23. You can configure up to 16 items of information to output from the
indicator. Press the UNITS key.
Display changes to DATA 2.
24. Repeat steps 21 and 22 above to configure up to 16 data items.
25. Press the SELECT key. . .
OUT is displayed.
26. Press the UNITS key. . .
IN is displayed.
27. Press the PRINT key.
DATA 1 is displayed.
28. Press the PRINT key.
The display will show something change to “000 FF”, or something
similar. The 000 is the type of input and the FF is the input token.
A list of input tokens and types is shown in Table 4.
