Model E1070 Indicator Service Manual
29. Use the TARE or UNITS key to change the input type. Use the SELECT
or PRINT key to change the input token. When the desired type and
token appear on the display, press the F1 key. . .
DATA 1 is displayed.
30. You can configure up to 16 items of information to input into the indica-
tor. Press the UNITS key.
DATA 2 is displayed.
31. Repeat steps 28 and 29 above to configure up to 16 data items.
32. Press the SELECT key.
IN is displayed.
33. Press the UNITS key.
TRADE is displayed.
34. Press the PRINT key to configure word swapping. Word swapping only
affects the output and/or input data if a long, unsigned long, or floating
point data type is used. These three data types are each made up of 4
bytes or 2 16-bit words. Word swapping will change the order that the
16-bit words are output/input.
The display will show either ON or OFF.
35. Use the TARE or UNITS key to toggle between the choices. When the
desired selection appears on the display, press either the F1 or PRINT
key.
TRADE is displayed.
36. Press the UNITS key.
ENDIAN is displayed.
37. Press the PRINT key.
The current setting is displayed. Choices are LITTLE or BIG.
38. Use the TARE or UNITS key to toggle between the choices. When the
desired selection appears on the display, press either the F1 or PRINT
key.
ENDIAN is displayed.
39. This completes the Remote IO configuration. Press SELECT to move
up the menu structure or press the ZERO key to exit the service menu.
Service Menu—OPTION submenu (continued)
