Model E1070 Indicator Service Manual
See Figure 14 to reference the
Supervisor’s menu.
10. Press the UNITS key. . .
PREACT is displayed. A preact is the time it takes an ingredient
(which is falling from an auger or other feeder) to reach the scale
after the auger or feeder is shut off. There will always be material
in “free-fall” after an ingredient is shut off and the indicator will
automatically calculate this and update this value.
The first time a batch is run, overage for any ingredient weight is
calculated and the next time the ingredient is being weighed the
output will be shut down so approximately 70% of the overage is
reduced. This occurs each time a batch is run so that the system
quickly learns and produces accurate batches.
Under this item you can turn the preact on or off, or clear a current
preact.
11. Press the PRINT key to set the preact. . .
ON or OFF is displayed.
12. Scroll through the choices (ON, OFF, CLEAR) with the TARE or UNITS
key. Press ENTER when your choice is displayed. . .
PREACT is displayed.
13. Press the UNITS key. . .
INGR X is displayed. X is the ingredient number. You have up to 8
ingredients for which you can set the following:
BASIS Set whether the ingredient is based on weight (Scale),
time (Time) or pulse counts (Cntr).
SETPT Set the output you want associated with the ingredi-
ent. Choices are 1, 2 , 3 or None.
DELAY Set a time delay between when a basis is met and the
next ingredient action is started.
14. Press the PRINT key. . .
BASIS is displayed.
15. Press the PRINT key. . .
The current setting is displayed; SCALE, TIME, or CNTR.
16. Scroll through the choices with the TARE or UNITS key. Press ENTER
when your choice is displayed. . .
If you choose SCALE you are prompted to enter an ingredient
weight. If you choose TIME, your are prompted to enter a time
value. If you choose CNTR, your are prompted to enter the
number of pulses.
17. Key in values and press the ENTER key. .
BASIS is displayed.
18. Press the UNITS key. . .
SETPT is displayed.
Supervisor Menu—(continued)
