92
Model E1070 Indicator Service Manual
1. From previous step 33, press the UNITS key. . .
TARGET is displayed. Use this item to print and clear reports for
the checkweigher application and to set the type of sampling to be
used, Limit or Sample.
2. Press the PRINT key. . .
PRINT is displayed. Use this item to print out a complete report of
checkweigher information.
3. Press the PRINT key . . .
Port 1 or PORT 2 is displayed. Use this item to select which port
to use for printing the report.
4. Toggle between PORT 1 and PORT 2 using the TARE or UNITS key.
Press the ENTER key when the choice you want is displayed. . .
Display shows BUSY briefly then returns to PRINT.
5. Press the UNITS key. . .
TYPE is displayed. Use this to choose the mode of setting the
target weight for the checkweighing application. You have two
choices; LIMIT and SPL (sample). See note at left.
LIMIT - In this mode you enter the upper and lower limits for your
item and the indicator will use those values to run the display.
SPL - In this mode you use a correct weight “product” on the scale
to set the target weight. The indicator will use this weight to run
the display. Upper and lower limits will automatically be 1 division
above and below the target weight respectively. Each colored
display graduation is equal to 1 scale division. The TARGET light
stays lit if weight is ±1 division of the target weight.
6. Toggle between the choices by pressing the TARE or UNITS key. Press
the ENTER key when your choice is displayed. . .
TYPE is displayed.
7. Press the UNITS key. . .
TRIPS is displayed. Use this to set outputs to follow over/under/
accept or to function as standard outputs.
8. Toggle between TARGET and STNDRD by using the TARE or UNITS
key:
TARGET OP1 is Under
OP2 is Accept
OP3 is Over
STANDARD You can configure outputs from weigh mode.
Generally Accept/Reject.
TARGET application
(Checkweighing)
You do not set the limits in this
menu item. Limits are set in
normal operation mode. This
menu item, TYPE, allows you
to set the mode of choosing
the target weight and limits.
Supervisor Menu—(continued)
If target trips are used, the
Gross Zero Band in the
Service>Scale menu must be
configured to something other
than 0. The OP1, OP2, or OP3
output will not turn off until the
scale returns to the gross zero
band.
To use Sample mode, both
multi-interval and preset tares
should be disabled. To disable
multi-interval, set the scales
division size to a whole number
(not 1/2, 2/5, 5/10, 10/20 or 20/
50). Preset tares are disabled
in the Supervisor>Setup>App>
PLU menu.
