Avigilon H5A User Manual

EN - English - Instruction manual
8 MNGCEVO_2116_EN
4 Product description and
type designation
The H5A Rugged PTZ camera is ideal as a video
surveillance solution for outdoor applications in
urban centres, critical infrastructures, traffic and
railways. It was designed to guarantee complete
reliability and continuous operation in more difficult
external environments and offer exceptional strength
against corrosion and a vast range of temperatures.
4.1 Product overview
The product consists of 3 parts:
1. Sunshield.
2. Body.
3. Base.
01
02
03
Fig. 1
4.2 Product marking label
Before proceeding further with installation,
make sure the material supplied
corresponds to the order specification by
examining the marking labels.
The product has a label applied in
compliance with CE marking.
Fig. 2
The label shows:
• Model identification code.
• Supply voltage (Volt).
• Frequency (Hertz).
• Current consumption (Amps).
• Protection degree (IP).
• Serial number.

Avigilon H5A Specifications

General

IR Illumination	Yes
Impact Protection	IK10
Local Storage	MicroSD card slot
Sensor Type	CMOS
WDR	Yes
Analytics	Object Detection, Unusual Motion Detection, Face Detection
Ingress Protection	IP66
Sensor	Progressive Scan CMOS
Lens	Motorized varifocal
Day/Night	Yes
Video Compression	H.264, H.265
Frame Rate	Up to 30 fps
Audio	Yes (2-way)
Power	PoE (IEEE 802.3af/at)
Onvif Compliance	Yes
Focal Length	2.8 mm to 12 mm
Minimum Illumination	0 lux
Network Interface	10/100 Ethernet
Resolution	Up to 8 MP (3840 x 2160)
Field of View	H: 108° to 32°
