Avigilon H5A User Manual

Instruction manual - English - EN
9MNGCEVO_2116_EN
4.3 Model identification
H5A RUGGED PTZ BASE CAMERA OPTIONS
Part Number Description
2.0C-H5A-RGDPTZ-DP36 H5A Rugged PTZ camera 2MP 36x-24Vac/dc
4.0C-H5A-RGDPTZ-DP36 H5A Rugged PTZ camera 4MP 36x-24Vac/dc
8.0C-H5A-RGDPTZ-DP36 H5A Rugged PTZ camera 8MP 36x-24Vac/dc
Tab. 1
OPTIONAL MOUNTS AND ACCESSORIES
Part number Description
AVUEI8AA Infrared illuminator 850nm for Avigilon H5A Rugged PTZ Camera, grey-white (RAL9002)
AVUEI8AAP IR illuminator 850nm for long distance lighting for Avigilon H5A Rugged PTZ Camera, grey-white colour
(RAL9002)
AVUEI9AA Infrared illuminator 940nm for Avigilon H5A Rugged PTZ Camera, grey-white (RAL9002)
AVUEIWAA White light illuminator 850nm for Avigilon H5A Rugged PTZ Camera, grey-white (RAL9002)
AVUEIWAAP White light illuminator for long distance lighting for Avigilon H5A Rugged PTZ Camera, grey-white
colour (RAL9002)
AVUEBP0AA Parapet bracket with internal cable channel for Avigilon H5A Rugged PTZ Camera, grey-white colour
(RAL9002)
AVUEBP4AA Parapet bracket with quick connectors RJ45 (Ethernet and PoE) + 4 poles for Avigilon H5A Rugged PTZ
Camera, grey-white (RAL9002)
AVUEBP7AA Parapet bracket with quick connectors RJ45 (Ethernet and PoE) + 7 poles for Avigilon H5A Rugged PTZ
Camera, grey-white (RAL9002)
AVUEBWAA Wall mount bracket for Avigilon H5A Rugged PTZ Camera, grey-white (RAL9002)
AVUEAP Pole adaptor in stainless steel AISI 316L
AVUEAC Corner adaptor in stainless steel AISI 316L
AVUEAW Counter-plate in stainless steel AISI 316L
AVCOMB100A Communication box in polycarbonate, 220Vac-230Vac
AVCOMB200A Communication box in polycarbonate, 24Vac
AVCOMB300A Communication box in polycarbonate, 120Vac-127Vac
AVWASPT0V5L5M00 Water tank 5l (1.3gal), pump with delivery up to 5m (16ft), IN 230Vac-24Vac-120Vac
AVWASPT0V23L11M00 Water tank 23l (6gal), pump with delivery up to 11m (36ft) with water floating, IN 230Vac-24Vac-120Vac
AVWASPT1V23L30M00 Water tank 23l (6gal), pump with delivery up to 30m (98ft) with water floating, IN 230Vac
AVWASPT3V23L30M00 Water tank 23l (6gal), pump with delivery up to 30m (98ft) with water floating, IN 120Vac
AVSURGEPR Lightning surge protection device for Ethernet line
POE-INJ-BT-90W-NA Gigabit 802.3bt 90W PoE Power Injector, single port
AVOUESUN04 Spare sunshield, grey-white (RAL9002)
AVOUEWIPER Spare wiper blade
AVOUEMAN Camera Maintenance Kit (1 x power connector, 1 x I/O connector, 1 x Plate for safety chain coupling, 2
x M16 cable glands, 1 x M20 cable gland, 1 x reduction gasket, for Ethernet cable with pre-assembled
connector, for cable gland M20, 1 x reduction gasket, for alarm cable, for cable gland M16, 1 x base
gasket, 1 x Allen wrench, 1 x 2.5A fuse)
Tab. 2
Refer to the instruction manual included with your accessory for more information on their installation and use.

Avigilon H5A Specifications

General

IR Illumination	Yes
Impact Protection	IK10
Local Storage	MicroSD card slot
Sensor Type	CMOS
WDR	Yes
Analytics	Object Detection, Unusual Motion Detection, Face Detection
Ingress Protection	IP66
Sensor	Progressive Scan CMOS
Lens	Motorized varifocal
Day/Night	Yes
Video Compression	H.264, H.265
Frame Rate	Up to 30 fps
Audio	Yes (2-way)
Power	PoE (IEEE 802.3af/at)
Onvif Compliance	Yes
Focal Length	2.8 mm to 12 mm
Minimum Illumination	0 lux
Network Interface	10/100 Ethernet
Resolution	Up to 8 MP (3840 x 2160)
Field of View	H: 108° to 32°
