Instruction manual - English - EN
11MNGCEVO_2116_EN
6 Installation
Never, under any circumstances, make any changes or connections that are not shown in this
handbook. Failure to follow the connection instructions that are given in the handbook may create
serious safety hazards for people and for the installation.
Do not change the wiring in the product as it is supplied to you. Failure to follow this instruction
may create serious safety hazards for people and for the installation, and will also invalidate the
warranty.
The product can be powered in 24Vac/24Vdc or via PoE 90W.
Keep the connection diagram for future reference.
6.1 Installation mode
The product can be installed in various modes using the supports and various adaptors available, meeting every
installation requirement.
6.1.1 Viewing angles
The figure displays the viewing angles of the tilt in the two installation modes (upright or inverted).
-90°
+90°
-40°
+90°
Fig. 4
