EN - English - Instruction manual
30 MNGCEVO_2116_EN
15 Technical data
CAUTION! TNV-1 installation type. The
installation is type TNV-1, do not connect it
to SELV circuits.
CAUTION! In order to reduce the risk of fire,
only use UL Listed or CSA certified cables
with sections greater than or equal to
0.14mm² (26AWG).
15.1 H5A Rugged PTZ camera
15.1.1 General
Easy installation thanks to the self-centring connector
Zero backlash
Quick configuration and setup
Dynamic positioning control system
Functions: Preset, Preset Tour (Patrol), Autoflip,
Autopan via Preset Tour
Maximum number of presets: 250
15.1.2 Mechanical
Constructed from aluminium and technopolymer
Epoxy-polyester powder painted, standard colour
grey-white (RAL9002)
Horizontal rotation: 360°, continuous rotation
Vertical rotation: from -90° up to +90° (inverted
installation, from -40° up to +90°)
Horizontal speed (variable): from 0.1°/s up to 250°/s
Tilt speed (variable): from 0.1°/s up to 250°/s
Accuracy of preset positions: 0.05°
Cable glands: 2xM16 + 1xM20 + special gasket for
pre-wired Ethernet cables
Unit weight: 7.1kg (15.6lb) (7.4kg (16.3lb) with LED
illuminator)
Glass window
Thick: 6mm (0.24in)
15.1.3 Electrical
Supply voltage/Current consumption:
PoE 90W using POE-INJ-BT-90W-NA. Device is
compatible with other IEEE802.3bt Class 8 power
sources, but operation is not guaranteed.
24Vac ±10%, 50/60Hz, 100VA max (aux power
supply)
24Vdc ±10%, 71W max (aux power supply)
Power consumption with illuminator off:
20W, PTZ stopped, heating switched off (with
the ECO-MODE function enabled, energy saving
function that is activated only when the PTZ is
stopped)
28W, PTZ stopped, heating switched off (with the
ECO-MODE function not enabled)
28W, PTZ in motion, heating switched off
51W, peak at start-up, heating and de-icing
functions switched on
Power consumption with illuminator on:
34W, PTZ stopped, heating switched off (with
the ECO-MODE function enabled, energy saving
function that is activated only when the PTZ is
stopped)
41W, PTZ stopped, heating switched off (with the
ECO-MODE function not enabled)
41W, PTZ in motion, heating switched off
66W, peak at start-up, heating and de-icing
functions switched on
Power supply cables section: from 0.75mm² (18AWG)
up to 2.5mm² (13AWG)
Cables signal section: from 0.14mm² (26AWG) up to
1mm² (17AWG)
Multipolar cable sheath diameter:
Cable glands M16: from 4.5mm (0.2in) up to
10mm (0.4in)
Cable glands M20: from 8mm (0.3in) up to 13mm
(0.5in)
Alarm inputs: 2 (auto-powered from 12Vdc up to
18Vdc)
Relay outputs: 2 (1A, 30Vac/30Vdc max)
15.1.4 Network
Ethernet connection: 100 Base-TX
Connector: RJ45
