15.1.5 Illuminators
LED illuminator
Wavelength: 850nm, 940nm (only AVUEIxxx), white
light
AVUEIxxx
• Wide beam: 40° (horizontal), 16° (vertical)
• Spot beam: 14° (horizontal), 14° (vertical)
AVUEIxxxP
• Wide beam: 13° (horizontal), 13° (vertical)
• Spot beam: 13° (horizontal), 13° (vertical)
Wide beam activation: based on the scene brightness,
from alarm input or manually
Spot beam activation (can be activated only when
the wide beam is active): can be activated on preset,
based on the zoom factor or with the wide beam
Automatic and remote switching on
No calibration required for light beam alignment with
the camera
The illuminator does not slow down the P&T’s
rotation speed
Automatic recognition of the type of illuminator
installed
15.1.6 Environment
For indoors and outdoors installation
Operating temperature
• Continuous functioning: from -40°C (-40°F) up to
+65°C (149°F)
• De-icing function intervention: from -40°C (-40°F)
up to -10°C (14°F)
Wind resistance
• PTZ static: 230km/h (143mph) max.
• PTZ in motion at the maximum speed with LED
illuminator: 230km/h (143mph) max.
Relative humidity: from 5% up to 95%

Avigilon H5A Specifications

General

IR Illumination	Yes
Impact Protection	IK10
Local Storage	MicroSD card slot
Sensor Type	CMOS
WDR	Yes
Analytics	Object Detection, Unusual Motion Detection, Face Detection
Ingress Protection	IP66
Sensor	Progressive Scan CMOS
Lens	Motorized varifocal
Day/Night	Yes
Video Compression	H.264, H.265
Frame Rate	Up to 30 fps
Audio	Yes (2-way)
Power	PoE (IEEE 802.3af/at)
Onvif Compliance	Yes
Focal Length	2.8 mm to 12 mm
Minimum Illumination	0 lux
Network Interface	10/100 Ethernet
Resolution	Up to 8 MP (3840 x 2160)
Field of View	H: 108° to 32°
