Axis Wake Research A20 - Underwater Lights

storage
• under bow seating (except when
optional bow tank installed)
• under observer seat
• under interior seating
• under driver’s seat
• watertight box on shifter panel
g3.2 tower
(may also include tower
accessories such as G-Force
Wet Sounds speakers and amps;
tow attachment; camera; lights;
mirror; racks)
subwoofer (where equipped,
under instrument panel)
engine exhaust
(beneath swim platform
on port & starboard sides)
underwater lights
(where equipped, under swim
platform)
ladder
(where equipped, under swim
platform)
surf gate,
auto-set wedge
(where equipped,
under swim platform)
transom
drain plug
center drain plug
batteries
(beneath observer seat)
battery charger
(where equipped)
glovebox (12V charger, USB
audio-only port, Aux-audio port)
battery (on-off)
(side panel in walk-thru)
cleat (where equipped)
cleat (where equipped)
amp
bilge, ballast, center
ballast, bow ballast
thru-hull outlets
(additional outlets aft port and
starboard and transom)
instrument panel
steering wheel
(options may be available)
shift/throttle control
fire extinguisher
indicator (where equipped)
fuel fill
cleat (where equipped)
engine compartment
automatic fire extinguisher
(where equipped)
stereo remote
(where equipped)
swim platform
circuit breaker panel
(under Shift/Throttle Control)
cleat (where equipped)
adjustable mirror (where equipped)
docking light (where equipped)
heater (where equipped, will have
2 or 3 vents in boat interior)
removable cooler
(under seat, where equipped)
zero off gps puck
2016 Axis Wake Research Owner’s Manual . . . Page 2-7
standard bow light or
pop-up bow light
(where equipped)
emergency safety stop
switch
docking light (where equipped)
ski pylon
