10 - 2011
3.3 CONFIGURATION OF THE CCTALK ADDRESSES OF THE DEVICES
•
The ccTalk device addresses of the Combo-T must be configured.
•
The ccTalk specification defines 1 as the bus address for the master. By default, the factory
default addresses of the Combo - T devices are as follows:
Coin Validator = address 2
Hopper or Discriminator 1 ( A ) = address 3
Hopper or Discriminator 2 ( B ) = address 4
Hopper or Discriminator 3 ( C ) = address 5
Interface board I/O = address 80
•
All ccTalk device addresses can be changed via a ccTalk command. The hoppers or
discriminators also allow address configuration with dipswitches
3.4 CONFIGURATION OF COIN ACCEPTANCE
•
From the Master, enable the acceptance of the coins to use in the validator.
•
By default and after being switched on, all coins are inhibited.
•
The cctalk command is used for the configuration of the inhibition [231] MODIFY INHIBIT
STATUS.
•
The status of the inhibitions can be requested via the command [230] REQUEST INHIBIT
STATUS.
3.5 CONFIGURATION OF THE COINS IN THE DISCRIMINATOR
If the Combo - T incorporates Discriminators, you must define the coins the device will work with. There
are specific ccTalk commands:
• [37] DIAMETER PROGRAMMING
• [49] PROGRAMMING THE VALUE
Consult the Discriminator ccTalk protocol specification for more information.
3.6 TEST
Before switching on, it is recommended to make a functional test with the device: acceptance of coins,
classification and return.
