10 - 2010
If multiple payment is used, the orders of payment must adapt to the current availability
of cash. It takes into account the availability and also the percentages of the types of
coins inside of the hopper. The duration of the payment will be extended proportionally
to the difference of percentages of occupation of the hopper.
• Out-of-change
In connection with the previous point - an algorithm of payment and refilling should be
used. Not refilling using useable inserted coins or uneven filling will often cause one coin
to be used up. If occupation of the capacity of the hopper is uneven, for the two types of
coins, the times of search are lengthened, much more as the difference between the two
are greater.
• Intelligent Payment
For the secure management of the cash it is recommended to use intelligent mode of
payment, in which the Discriminator uses the coins as and how they are in the disk at
the time of the transaction to complete the payment of the amount requested. In
addition, the intelligent payment tries to save coins of the lowest value for a future
assurance of the payment.
.
5.6.2 Technical Characteristics
• Interface ccTalk.
• Coverage of all the range of existing coins with 3 available disks (diameter) 7, 8 and 12
cavities and two blades (thickness)
• Storage of up to two types of coin per hopper
• Up to 400 coins per hopper average for a coin of 24 mm dia. and 2.8 mm thickness
• Optical sensors of detection of levels: full and empty
• Optical sensor for the detection exiting coins
• Exit gate for stopping coins
• Reporting of errors through the ccTalk bus
• Possibility of encrypted operation with the ccTalk standard
• Average speed of payout of 5.6 coins/s, reaching a maximum speed of 8 coins/s for
lower diameters
• Anti-jam function software and detection of current draw. Reverses the rotation of the
engine for 1.5 s, in case of detection, to remove the jam
• Anti-cave or hollow function for a lack of payment due to coins not reaching the disk, the
rotation of the motor is inverted to mix up all the coins in the hopper so the reach the
disk. It waits for 5 seconds with no extraction of coins and activates. The rotation of the
motor is reversed for 1.5
