Payment commands
Table 33: Payment commands
5.6.7 Calibration of the Discriminator
The calibration is the process of memorization of the measurements of the coins with which you
are going to work. It also makes the adjustment of the offset of the different measurement
sensors, referencing them with a known parameter, such as the diameter of the coin.
All the Discriminators leave factory calibrated, however, it is necessary to make a recalibration
when you remove or change any of the following elements of measurement in the Discriminator:
− Encoder
− Trigger
− Disk
− Blade
− Electronics of the optic sensors
− Optic sensors
It is recommended to do recalibration if the hopper has any physical wear in any of the moving
parts or if it has been dropped or suffered a hard knock.
Code Command
standard ccTalk /
Specific for discriminator
[10H] About discriminator
[13H] Request for status discriminator
[15H] Cancellation discriminator
[19H] Multiple emptying discriminator
[20H] Multiple payment discriminator
[23H] Last command status discriminator
[35H] Intelligent payout discriminator
[A3H]
Test hopper standard ccTalk
[A4H] Enable hopper standard ccTalk
[A6H] Request hopper status standard ccTalk
[A7H]
Dispense hopper coins standard ccTalk
[A8H]
Request hopper dispense count standard ccTalk
[ACH] Emergency stop standard ccTalk
