10 - 2011
5.5.1 Technical Characteristics
• Coverage of all the range of existing coins with 3 available disks (diameter) 7, 8 and 12 cavities and two
blades (thickness)
• Storage of one type of coin per hopper
• Up to 400 coins per hopper average for a coin of 24 mm dia. and 2.8 mm thickness
• Optical sensors of detection of levels: full and empty
• Optical sensor for the detection exiting coins
• Possibility of detecting double counting, which consists of an additional sensor in the output for an
increase in security
• Reporting of errors through the ccTalk bus
• Possibility of encrypted operation with the ccTalk standard
• Average speed of payout of 5.6 coins/s, reaching a maximum speed of 8 coins/s for lower diameters
• Anti-jam function software and detection of current draw. Reverses the rotation of the engine for 1.5 s, in
case of detection, to remove the jam
• Anti-cave or hollow function for a lack of payment due to coins not reaching the disk, the rotation of the
motor is inverted to mix up all the coins in the hopper so the reach the disk. It activates after 5 seconds
with no extraction of coins and activates. The rotation of the motor is reversed for 1.5 seconds
5.5.2 Physical characteristics
Range of coins
Table 15: Range of coins of the hopper
Capacity of coins in the hopper
Table 16: Capacity of coins in the hopper
Range diameter coin (mm) 12 to 32
Range thickness coins (mm) 1.2 to 3.5
Coin
Ø 24 mm
Thickness
2,8 mm
5
cent €
10
cent €
20
cent €
50
cent €
1
€
2
€
Hopper - medium
400 775 775 600 375 425 325
