10 - 2010
Espadín largo Espadín corto
Types of extraction disks
Figure 17: Extraction disks
Table 17: Range of coins for type of disk
Types of blade
Figure 18: Blades
Table 18: Range of coins for type of blade
Type of disk Diameter of coins (mm) Speed of payment (m/s)
7 cavities 30 to 32 4,6
8 cavities 18 to 30 5,3
12 cavities 12 to 20 8
Blade Thickness of coins (mm) Para disk
Short 1.7 to 3.2 7 and 8 cavities
Short reduced 1.2 to 1.7 7 and 8 cavities
Long* 1.2 to 3.3 12 cavities
* For thinner coins, consult with the Dept.
CRM – after-sales Azkoyen - Ampasa
