5.3.3 Physical characteristics
In the following table the range of diameters and thicknesses of the coins accepted by the different
classification paths.
Table 6: Physical characteristics of the paths
5.3.4 Electrical characteristics
•
Voltage of power supply
V power supply
Activation
12-24VDC ± 10%
•
Current draw
Tables 8: Voltage of the power supply and current draw
5.3.5 Electronic circuit board and connections
On the Electronic circuit board are the internal and external connections.
The coin validator is connected to the Combo-T device with 10-way cable that comes with the sorter.
Alternatively the ccTalk connection could be made with the 4-way connector available.
Number of path S1 (C1) S2 (C2) S3 (C3) S4 (C4) S5 (C5)
Range of diameter of coins (mm) 16.25 to 32.5
16.25 to 29 16.25 to 29
16.25 to 29 16.25 to 29
Range of thickness of coins
(mm)
1.2 to 3.2 1.2 to 3.2 1.2 to 3.2
1.2 to 3.2
1.2 to 3.2
Current draw
Activation (max.) 500 mA
